Choosing a new Mac often involves consideration of the many Apple silicon chips now on offer, so our comprehensive guide covers their generations, variations, performance benchmarks, and future prospects to help you decide which is best for you.
After iterating for over a decade in the iPhone and iPad, Apple in 2020 brought its custom silicon chip technology to the Mac, enabling major performance and power efficiency improvements. Since then, Apple silicon has expanded to every Mac model, spurring new designs and capabilities that were previously impossible.
Understanding the distinctions between Apple silicon chips will help you make an informed decision when selecting the right Mac for your needs. There have been two generations of Apple silicon for the Mac, each with four different chip variants. The main differences between the four different chip variants are as follows:
M1 and M2: Standard Apple silicon chip with a balance of performance and power-efficiency.
M1 Pro and M2 Pro: Apple silicon chip with additional high-performance CPU cores and twice the memory bandwidth of the M2 chip (200GB/s).
M1 Max and M2 Max: Doubles the GPU cores and memory bandwidth (400GB/s) of the M1 Pro or ?M2? Pro chips for better graphics performance.
M1 Ultra and M2 Ultra: Encompasses two M1 Max or ?M2? Max chips for double overall CPU and GPU performance, as well as twice the memory bandwidth (800GB/s).
Apple Silicon Generations
With the introduction of the ?M2? series of chips in 2022, Apple made some key improvements over the initial M1 series from 2020.
The below table provides a comparison between the ?M1? and ?M2? series, highlighting differences in the chips they are based on, node, CPU clock speed, Neural Engines, and more:
?M1? Series
?M2? Series
Based on A14 Bionic chip from iPhone 12
Based on A15 Bionic chip from iPhone 13
5nm node (N5)
Enhanced 5nm node (N5P)
3.20 GHz CPU clock speed
3.49 GHz CPU clock speed
High-performance “Firestorm” and energy-efficient “Icestorm” cores
High-performance “Avalanche” and energy-efficient “Blizzard” cores
Neural Engine
40 percent faster Neural Engine
Video decode engine
Higher-bandwidth video decode engine
Image signal processor (ISP)
“New” image signal processor (ISP)
Launched November 2020 to March 2022
Launched June 2022 to early 2024
The standard ?M2? chip also features several additional changes over its ?M1? predecessor, including:
?M1?
?M2?
68.25GB/s memory bandwidth
100GB/s memory bandwidth
Media engine for hardware-accelerated H.264 and HEVC
Media engine for hardware-accelerated H.264, HEVC, ProRes, and ProRes RAW
–
ProRes encode and decode engine
It is worth noting that all Apple silicon chips other than the ?M1? chip contain media engines for hardware-accelerated H.264, HEVC, ProRes, and ProRes RAW video.
Devices
Each Apple silicon chip is only available in a select number of Apple devices. The standard ?M1? and ?M2? chips are present in a large number of laptop and desktop devices, several ?iPad? models, and even the upcoming Vision Pro headset, owing to their requirement for a balance of performance and efficiency. On the other hand, the ?M2? Ultra, Apple’s most powerful custom silicon chip to date, is only available in the high-end Mac Studio and Mac Pro.
(Standard)
Pro
Max
Ultra
?M1?
MacBook Air (2020)
Mac mini (2020)
MacBook Pro (13-inch, 2020)
iMac (2021)
iPad Pro (2021)
iPad Air (2022)
MacBook Pro (14-inch and 16-inch, 2021)
MacBook Pro (14-inch and 16-inch, 2021)
?Mac Studio? (2022)
?Mac Studio? (2022)
?M2?
?MacBook Air? (2022, 2023)
MacBook Pro (13-inch, 2022)
?iPad Pro? (2022)
Mac Mini (2023)
Vision Pro (2024)
MacBook Pro (14-inch and 16-inch, 2023)
?Mac mini? (2023)
MacBook Pro (14-inch and 16-inch, 2023)
?Mac Studio? (2023)
?Mac Studio? (2023)
?Mac Pro? (2023)
CPU and GPU Cores
CPU cores are individual processing units within a Central Processing Unit (CPU) responsible for executing instructions and performing general-purpose tasks, while GPU cores are specialized units within a Graphics Processing Unit (GPU) designed for parallel processing and graphics-intensive tasks.
The number of CPU and GPU cores in an Apple silicon chip impacts the performance and multitasking capabilities of a Mac, with more cores leading to faster and more efficient execution of tasks, especially in intensive workloads. The table below presents a comparison of the core configurations and GPU specifications for the different variants of the ?M1? and ?M2? chips:
(Standard)
Pro
Max
Ultra
?M1?
4 high-performance cores
4 energy-efficient cores
7- or 8-core GPU
6 or 8 high-performance cores
2 energy-efficient cores
14- or 16-core GPU
8 high-performance cores
2 energy-efficient cores
24- or 32-core GPU
16 high-performance cores
4 energy-efficient cores
48- or 64-core GPU
?M2?
4 high-performance cores
4 energy-efficient cores
8- or 10-core GPU
6 or 8 high-performance cores
4 energy-efficient cores
16- or 19-core GPU
8 high-performance cores
4 energy-efficient cores
30- or 38-core GPU
16 high-performance cores
8 energy-efficient cores
60- or 76-core GPU
Deciding how many CPU cores you need depends on the specific tasks and workflows you intend to perform on your Mac. For example, if you primarily engage in basic tasks like web browsing, document editing, and media consumption, an eight-core chip should suffice. On the other hand, if you work with demanding workloads like software development, opting for a higher core count can provide significant performance benefits. Similarly, graphics-intense workflows like video editing, 3D modeling, or gaming will benefit from additional GPU cores.
Benchmarks
Computer benchmark scores are standardized measurements that evaluate the performance of chips, providing a numerical representation for comparing capabilities and assessing performance against industry standards. The data on this chart is calculated from Geekbench 6 results users uploaded to Geekbench. Geekbench 6 scores are calibrated against a baseline score of 2,500 (which is the score of an Intel Core i7-12700 performing the same task).
The below Geekbench 6 scores show the range from the lowest specification chip in the least powerful Mac to the highest specification chip in the most powerful Mac.
(Standard)
Pro
Max
Ultra
?M1?
Single-Core: 2,324–2,346
Multi-Core: 8,204–8,368
Metal: 31,549
Single-Core: 2,359–2,371
Multi-Core: 10,276–12,132
Metal: 64,096
Single-Core: 2,369–2,397
Multi-Core: 12,108–12,369
Metal: 108,584
Single-Core: 2,381
Multi-Core: 17,677
Metal: 152,706
?M2?
Single-Core: 2,561–2,625
Multi-Core: 9,583–9,687
Metal: 42,573
Single-Core: 2,633–2,647
Multi-Core: 12,028–14,203
Metal: 76,304
Single-Core: 2,730–
Multi-Core: 14,405–
Metal: 131,408
Single-Core:
Multi-Core:
Metal: 208,028
Both the ?M1? and ?M2? chips demonstrate significant performance improvements in single-core and multi-core tasks as you move from the base to the Ultra variants, with the ?M2? chip showcasing even higher performance across the board. Nevertheless, it is worth noting that benchmarks do not tell the whole story. Benchmarks focus on specific tasks and synthetic workloads, and do not always accurately capture real-world usage scenarios and variations.
Unified Memory
Apple silicon chips have a unified memory architecture, meaning that the RAM is tied directly to the processor for maximum speed and efficiency. This means that the chip you choose determines what memory option are available, and it is not upgradable at a later date.
(Standard)
Pro
Max
Ultra
?M1?
8GB
16GB
16GB
32GB
32GB
64GB
64GB
128GB
?M2?
8GB
18GB
24GB
16GB
32GB
32GB
64GB
96GB
64GB
128GB
192GB
Deciding how much RAM you need depends on your specific tasks and usage patterns. 8GB should be enough for most users, but upgrading to 16GB or 24GB could be sensible for users with more intense multitasking requirements. Amounts of memory beyond 32GB are generally reserved for seriously demanding workflows.
Final Thoughts
Overall, if you are new to Apple silicon and are still not sure which chip to buy, use the following rationale:
Buy M1 or M2 if… you need a good balance of price, performance, and battery life and have normal day-to-day computing requirements.
Buy M1 Pro or M2 Pro if… you need a performance-focused chip for slightly more intense workflows.
Buy M1 Max or M2 Max if… you need additional graphics performance for working with images, videos, graphic design, or games.
Buy M1 Ultra or M2 Ultra if… you need the best possible overall performance for extremely intense professional workflows.
It is generally not worth upgrading from any of the individual ?M1? chips to their direct successors and it may be better to wait for Apple to launch the M3 series of chips. Apple has not yet released any M3-series chips, but the company is rumored to launch the ?M3? chip toward the end of 2023. It is expected to be Apple’s first chip based on TSMC’s 3nm process, a significantly smaller node, which should lead to major performance and efficiency improvements over the ?M1? and ?M2? chips that are currently on offer.Related Roundups: iMac, Mac Studio, MacBook Air, MacBook Pro 13″, MacBook Pro 14 & 16″ , Mac mini, Mac ProTag: Apple SiliconBuyer’s Guide: iMac (Don’t Buy), Mac Studio (Buy Now), 15″ MacBook Air (Buy Now), 13″ MacBook Pro (Don’t Buy), 14″ & 16″ MacBook Pro (Neutral), 13″ MacBook Air (Caution), Mac Mini (Buy Now), Mac Pro (Buy Now)Related Forums: iMac, Mac Studio, MacBook Air, MacBook Pro, Mac mini, Mac ProThis article, “Apple Silicon Buyer’s Guide: All the Differences Explained” first appeared on MacRumors.comDiscuss this article in our forums
